7 T
o move a measurement, drag it to a new locaon.
8 To edit a measurement, drag an end point or the apex to a new locaon.
9 To delete a measurement, select the measurement and click Delete in the task panel.
You can also delete the selected measurement using Delete on the keyboard, or from the shortcut
menu aer right-clicking a measurement.
8.14.5 Creang an Open Angle Measurement
An open angle measurement displays the angle between two lines that are not joined at an apex.
1 Select the Processing task and click Calibraon and Measurements to display the available
measurement opons.
2 If the automac calibraon factor is available, click Accept.
If the automac calibraon factor is not available, you should perform manual calibraon before
creang a measurement. For informaon, see Manual Calibraon (page 144).
3 Click Open Angle.
4 Click in the image at the start point of the rst line, then click again at the end point.
5 Click at the start point of the second line, then click again at the end point.
The two lines and the value of the angle between them are displayed in the image.
6 To move a measurement, drag it to a new locaon.
7 To edit a measurement, drag an end point to a new locaon.
8 To delete a measurement, select the measurement and click Delete in the task panel.
You can also delete the selected measurement using Delete on the keyboard, or from the shortcut
menu aer right-clicking a measurement.
8.14.6 Manual Calibraon
To ensure accurate measurements, the measurement funcon must be calibrated.
You can perform manual calibraon using one of the following methods:
• Catheter
• Distance
• Sphere
NOTE When performing manual calibraon on biplane images, you must perform calibraon on
frontal image and the lateral image separately.
Catheter Calibr
aon
You perform catheter calibraon by tracing the centerline of a catheter in the image.
You can perform catheter calibraon on either a straight catheter segment or a curved segment, but
you should always use a non-tapered segment. Using a tapered segment for calibraon will result in
incorrect measurement results.
1 In the Calibraon and Measurements task panel, click Manual Calibraon to display the
Calibraon dialog box.
2 In the Cal. Method list, select Catheter.
Processing Creang Measur
ements
Azurion Release 1.2 Ins
trucons for Use 144 Philips Healthcare 4522 203 52421
