Philips Azurion - Page 314

1
2
3
3
2
2
4
5
6
7
Figure 135 T
echnique factors graph (all dimensions are in cm)
Legend
1 Scaer object: 25 x 25 x 15cm PMMA
(IE
C60601-1-3 / IEC60601-2-54)
5 Dose (mGy/hour)
2 Radiaon shields 6 Dose (mGy/hour) with shield (0.5 mm Pb equiva-
lent)
3 Signicant zone of occupaon (LxWxH): 60 x 60 x
200 cm (located 10 cm from the radiaon shield)
7 Dose (mGy/hour) without shield
4 Height (cm)
NOTE Radiaon shields lo
wer the AK by at least one order of magnitude.
The indicated signicant zone of occupancy is designated to be used for radiologic procedures
according to the intended use of the equipment. For details, see Intended Use of the System (page 16).
Technical Informaon Protecon Against Stray Radiaon
Azurion Release 1.2 Ins
trucons for Use 314 Philips Healthcare 4522 203 52421
