Emission test Compliance Guidance
Conducted Emissions
150 kHz - 30 MHz
CISPR 11
Group 1 Class A The system is suitable for use in all establishments other
than domesc and those dir
ectly connected to the public
low-voltage power supply network that supplies buildings
used for domesc purposes.
Harmonic emissions
IEC 61000-3-2
Not applicable
Voltage uctuaons/Flicker
emissions
IEC 61000-3-3
Not applicable
Electromagnec Immunity
The f
ollowing table provides the manufacturer's declaraon and guidance concerning electromagnec
immunity.
Immunity Test IEC 60601 Test Level Compliance Level Guidance
Electrostac dischar
ge (ESD)
IEC 61000-4-2
± 2 kV, ± 4 kV, and ± 6 kV
contact
± 2 kV, ± 4 kV, and ± 8 kV air
± 6 kV contact
± 8 kV air
Floors should be wood, con-
crete or ceramic le. If
oors are covered with syn-
thec material, the relave
humidity should be at least
30%.
Electrical fast transient/
burst
IEC 61000-4-4
± 2 kV for power supply
lines
± 1 kV for input/output lines
± 2 kV for power supply
lines on cables >3 m
± 1 kV for input/output lines
Mains power quality should
be that of a typical commer-
cial or hospital environ-
ment, and should meet the
requirements of EN50160
or equivalent.
Surge
IEC 61000-4-5
±0.5kV, ±1kV and ±2kV for
external power supply lines,
line to earth
±0.5kV and ±1kV for exter-
nal power supply lines, line
to line
± 1 kV dierenal mode
± 2 kV common mode
Mains power quality should
be that of a typical commer-
cial or hospital environ-
ment, and should meet the
requirements of EN50160
or equivalent.
Voltage dips, short interrup-
ons and voltage variaons
on power supply input lines
1
IEC 61000-4-11
<5% U
T
2
(>95% dip in U
T
) f
or 0.5 cy-
cle
40% U
T
2
(60% dip in U
T
) for 5 cycles
70% U
T
2
(30% dip in U
T
) for 25 cycles
<5% U
T
(>95% dip in U
T
) for 5s.
<5% U
T
(>95% dip in U
T
) f
or 0.5 cy-
cle
40% U
T
(60% dip in U
T
) for 5 cycles
70% U
T
(30% dip in U
T
) for 25 cycles
<5% U
T
(>95% dip in U
T
) for 5s.
Mains power quality should
be tha
t of a typical commer-
cial or hospital environ-
ment, and should meet the
requirements of EN50160
or equivalent.
Power frequency
(50/60 Hz)
magnec eld
IE
C 61000-4-8
3 A/m 3 A/m Power frequency magnec
elds should be at levels
characterisc of a typical lo-
caon in a typical commer-
cial or hospital environ-
ment.
1
The s
ystem has been tested and found to be compliant with the YY0505 and IEC60601–1–2 standards. The voltage dip
and variaon tests of clause 36.202.7.a1 (table 210) have not been applied to the 3-phase supply mains interface of this
system because this interface is exempt from these tests by clause 36.202.7.a1 for the following reasons:
• The Azurion system is not life-supporng equipment.
• The rated input current on the 3-phase supply mains interface exceeds 16 A.
• The voltage interrupon test of clause 36.202.7.a2 (table 211) has been applied on the 3-phase supply mains interface
and passed.
2
Applies t
o single phase external supply mains interfaces only, and is not applicable to 3-phase supply mains since the
input current rang is higher than 16 A.
NOTE U
T
is the A
C mains voltage prior to applicaon of the test level.
Technical In
formaon Electromagnec Compability
Azurion Release 1.2 Ins
trucons for Use 323 Philips Healthcare 4522 203 52421
