1
2
3 4
Figure 181 R
eview window
Legend
1 Main na
vigaon area 3 Applicaon message area
2 Applicaon area
On biplane systems, images from the frontal chan-
nel and the lateral channel are displayed side by
side, and are synchronized.
4 Nocaon area
Main Na
vigaon Area
The main navigaon area displays the following items:
Paent selector: Click this buon to open the paent database for paent and study administraon.
Acquision tabs:
• Viewer tab: Click this tab to view the series currently being reviewed.
• More Tools tab: Click this tab to display a list of available tools. When a tool is selected a tab for the
selected tool is added.
Paent informaon panel:
• This panel displays informaon about the acquision paent. The expander buon opens an
overview panel containing details of the study, including the ProcedureCard.
• Warning messages related to the paent are also displayed here, for example, if the paent has
allergies.
Close Study: Click this buon to close the study.
System menu: This menu contains opons for system conguraon.
Help menu: This menu provides access to the following:
• Electronic Instrucons for Use
• Informaon about the system
Quick Reference WorkSpot
