Tool Funcon Descripon
Zoom Zoom the image
Pan Pan the image
Contrast and Brightness Adjust the contrast and brightness of the image
Edge enhancement Sharpen or soen edg
es in the image
Intervenonal r
oom pointer Acvate the image pointer
Subtracon Switch sub
tracon on or o
Pixel shi Reposion the mask imag
e
Landmarking Apply landmarking
Fluoro store Store uor
oscopy images
Copy to Reference 1
Copy the current image to the Reference 1 window
On biplane s
ystems, the frontal image is copied.
Copy to Reference 2
Copy the current image to the Reference 2 window
On biplane s
ystems, the lateral image is copied.
Copy to Reference 3
Copy the current image to the Reference 3 window
On biplane s
ystems, images from both channels are copied, and are dis-
played side by side and synchronized.
Flag image Flag the current image
Flag series Flag the current series
Link image processing (bi-
plane s
ystems only)
Sets the scope when processing biplane images:
• Biplane Unlinked: Changes can be applied independently to both the
frontal and lateral images
• Biplane Linked: Changes applied to one image are automacally ap-
plied to both the frontal and lateral images
Snapshot Copy the current image as a photo image
Quantave Cor
onary Anal-
ysis
Starts Quantave Coronary Analysis
Quantave V
ascular Analy-
sis
Starts Quantave Vascular Analysis
Le V
entricular Analysis Starts Le Ventricular Analysis
Biplane Le V
entricular
Analysis
Starts Biplane Le Ventricular Analysis
Right Ventricular Analysis Starts Right Ventricular Analysis
