Figure 196 Body z
ones
Legend
1 Head 3 Abdomen
2 Thorax 4 Peripheral
The dose model is further r
ened for the thorax body zone, as dened in the exposure procedure X-ray
protocols.
For the thorax body zone, the skin is modeled as a sphere of 30 cm diameter, posioned around the
isocenter. The surface of this sphere is divided into 10 areas corresponding to dierent projecons of
the X-ray beam: ve at the cranial side and ve at the caudal side.
Figure 197 Dose model applied in the ar
ea corresponding to the current posion (rotaon and
angulaon) of the stand
Figure 198 Dose model displa
yed in the dose report
