Figure 45 Con
trol module
Legend
1 Emergency stop
2 Table override
Emergency Stop
The emer
gency stop buon stops any motorized movement by switching the geometry funcons o.
The geometry funcons become operaonal again aer a geometry restart.
To perform a geometry restart, press Power On on the review module.
Table Override
Move the joysck downward to acvate the override mode.
0
1
2
3 4
Figure 46 T
op view of the paent table
Legend
1 Doctor side 3 Head end
2 Nurse side 4 Foot end
WARNING
The s
ystem has limited collision prevenon funconality when used in combinaon with a Trumpf
table. When moving the X-ray system or the table manually or under motor control, take care to
avoid collisions with the paent or objects.
NOTE The X-ray system paen
t orientaon posion informaon is inaccurate since it is based on
the horizontal table posion and is independent of the posion of the Trumpf table.
Preparing a P
aent Study Using an OR Table
