CLI Commands
4.16 S
SCALANCE W1750D CLI
Function Manual, 03/2019, C79000-G8976-C452-04
379
Display the Potential AP table. The Potential AP table shows the following
data:
• bssid: The BSSID of the AP.
• channel: e current radio channel of the AP
• phy type: The radio’s PHY type. Possible values are 802.11a,
802.11a-HT-40, 802.11b/g, 802.11b/g-HT-20.
• num-beacons: Number of beacons seen during a 10-second scan
• tot-beacons: Total number of beacons seen since the last reset.
• num-frames: Total number of frames seen since the last rest.
• mt: Monitor time; the number of timer ticks elapsed since the first AP
is recognized.
• at: Active time, in timer ticks.
• ibss: Shows if ad-hoc BSS is enabled or disabled. It will be enabled if
the bssid has detected an ad-hoc BSS (an ibss bit in an 802.11
frame).
• rssi: The RSSI value displayed in the output of this command repre-
sents signal strength as a signal to noise ratio.
For example, a value of 30 would indicate that the power of the received
signal is 30 dBm above the signal noise threshold.
Shows the Potential client table. The Potential Client table shows the
following values:
• last-bssid: the Last BSSID to which the client associated.
• from-bssid,
• to-bssid
• mt:Monitor time; the number of timer ticks elapsed since the first client
is recognized.
• it: Client Idle time, expressed as a number of timer ticks.
Displays rogue APs information for the current AP.
Shows the Router MAC Addresses that were learned. The output of this
command includes the router’s MAC address, IP address and uptime.
Shows scanned information for the AP.
Shows the configuration and status of monitor information of the AP.
Shows the AP monitoring state.
Shows the AP monitoring statistics.
Shows the status of the AP monitoring.
Example
show ap monitor active-laser-beams
The following example shows the output of
show ap monitor active-laser-beams command:
Active Laser Beam Sources
-------------------------
bssid channel rssi ap name lms ip master ip inactive time
