September 2006 Replacement and Adjustment
B706-19
Peripherals
3.7 SHIFT TRAY MOTOR
1. Remove the front door and rear cover ( 3.1).
2. Shift motor [A] ( x 2, x 3)
B478R531.WMF
[A]
06/09
