September 2006 PICK-UP SOLENOID
B473-3
Peripherals
1.3 PICK-UP SOLENOID
Rear cover ( x4)
Open the transport cover ( 1.2)
Bracket cover ( 2.2)
[A]: Pick-up solenoid ( x2, x1)
B473R004.WMF
[A]
06/09
