SERVICE TABLES September 2006
B706-32
5. SERVICE TABLES
For details about 3000-Sheet Finisher B706 SP codes, please refer to “5. Service
Tables” in the main machine service manual.
5.1 DIP SWITCHES
DPS100
1 2 3 4
Description
0 0 0 0 Default
0 0 1 0 Free run: A4 LEF, staple mode
0 0 0 1 Free run: staple and tray shift
NOTE: Do not use any other settings.
5.2 TEST POINTS
No. Label Monitored Signal
TP100 (5V) +5 V
TP101 (GND) Ground
TP102 (RXD) RXD
TP103 (TXD) TXD
5.3 FUSES
No. Function
FU100 Protects 24 V.
06/09
