PICK-UP/FEED/
SEPARATION ROLLERS
September 2006
B473-2
1.2 PICK-UP/FEED/SEP
ARA
TION
ROLLERS
[A]:
Open the transport cov
er
[B]:
Bracket cover (
x2)
[C]:
Pick-up roller (
x1)
[D]:
Feed roller (
x1)
[E]:
Separation roll
er (
x1)
B473R002.
WMF
B473R003.
WMF
[C]
[D]
[E]
[B]
[A]
06/09
