Toshiba e-STUDIO4500c Service Manual

PM TABLES August, 2006
2-10
ARDF PM Parts
NOTE: The "K" number in the table below is the number of originals that have
been fed.
Every PM
Visit
Every
120K
EM Note
External Covers I, C
Feed Belt C R R
Pick-up Roller C R R
Separation Roller C R R
Alcohol or water, dry
cloth
Original Length Sensors
Skew Correction Sensor
Interval Sensor
Registration Sensor
Paper Exit Sensor
Lower Inverter Sensor
Separation Sensor
Upper Inverter Sensor
C C
Blower brush
White Cover C C
Transport Belt C R C
Alcohol or water, dry
cloth
Feed Drive Gears L G501 Grease
Grip Roller C
Transport Rollers C
Scanner Rollers (Entrance/Exit) C
Exit Rollers C
Inverter Rollers (Lower, Exit,
Upper)
C
Idle Rollers C
Alcohol or water, dry
cloth
