Toshiba e-STUDIO4500c - Tray

August, 2006 Machine Configuration
Spec-21
No. Component Function
MECHANICAL CLUTCHES
MC1 Bypass Feed Clutch
Engages and operates the pick-up roller at the bypass
tray.
MC2 Toner Pump Clutch - M
Engages the and drives the Magenta toner pump to pull
toner from the Magenta STC.
MC3 Toner Supply Clutch - M
Engages the toner supply coils in the sub hopper of the
Magenta PCU to send toner to the development unit
below.
MC4 Toner Pump Clutch - K
Engages the and drives the Black toner pump to pull
toner from the Black STC.
MC5 Toner Supply Clutch - K
Engages the toner supply coils in the sub hopper of the
Black PCU to send toner to the development unit below.
MC6 Toner Pump Clutch - Y
Engages the drive shaft and rotor of the Yellow toner
pump to pull toner from the Yellow STC when more
toner is needed.
MC7 Toner Supply Clutch - Y
Engages the toner supply coils in the sub hopper of the
Yellow PCU to send toner to the development unit
below.
MC8 Toner Pump Clutch - C
Engages the and drives the Cyan toner pump to pull
toner from the Cyan STC.
MC9 Toner Supply Clutch - C
Engages the toner supply coils in the sub hopper of the
Cyan PCU to send toner to the development unit below.
