BOARDS August, 2006
3-138
3.14.5 RDS BOARD, JUMPER
Remove:
• Controller unit (3.14.1)
• Interface board (3.14.6)
[A]: RDS board ( x, x)
[B]: Jumper
B132R709.WMF
[A]
[B]
