2.3 PM TABLES
2.3.1 MAIN MACHINE
Symbol Key for PM Tables
I: Inspect. Clean, replace, or lubricate as needed.
C: Cleaning required.
R: Replacement required.
L: Lubrication required.
Silicone Grease 501 (52039502)
Grease Barrierta – S552R (A2579300)
Grease – KS660 – SHIN-ETSU (G0049668)
Heat Resisting Grease MT-78 (54479078)
Launa Oil 40 (54429103)
EM:
Emergency Maintenance
Copier PM Parts
150K
300K 600K EM Note
OPTICS
Reflector C Optical cloth
1st Mirror C Optical cloth
2nd Mirror C Optical cloth
3rd Mirror C Optical cloth
Scanner Rails C Alcohol then dry cloth
Exposure Glass C Exposure glass cleaner
Toner Shield Glass C Optical cloth
APS Sensor C Dry cloth
ARDF Exposure Glass C Exposure glass cleaner
Dust Filters C Blow brush
