REPLACEMENT AND ADJUSTMENT September 2006
B706-6
3.2 ROLLERS
3.2.1 SHIFT POSITIONING ROLLER
1. Above the shift tray, pull the roller mount [A] out.
2. Remove the rollers [B] and [C] ( x 1 each)
B478R522.WMF
[A]
[B]
[C]
06/09
