Toshiba e-STUDIO4500c Service Manual

WASTE TONER COLLECTION August, 2006
6-70
6.10 WASTE TONER COLLECTION
6.10.1 WASTE TONER PATH
[A]: Waste Toner Collection Coils
 PCU (Y)
 PCU (C)
 PCU (M)
 PCU (K)
 ITB Unit
 PTR Unit
[B]: Horizontal Waste Toner Transport Coil
[C]: Vertical Waste Toner Transport Coil
[D]: Diagonal Waste Toner Transport Coil
[E]: Waste Toner Bottle Transport Coil
[F]: Waste Toner Bottle Distribution Coil
B132D215.WMF






[B]
[C]
[D]
[A]
[E]
[F]
