August, 2006 COPY TRAY (B756)
1-39
Installation
1.4 COPY TRAY (B756)
1.4.1 ACCESSORIES
Check the accessories and their quantities against this list.
Description Q’ty
1. Copy Tray ........................................................................... 1
2. Actuator Arm and Bracket (not used).................................. 1
3. Tapping Screw (not used)................................................... 2
4. Large Cap........................................................................... 1
5. Small Cap ........................................................................... 4
6. Tapping Screw (M4 x 8)...................................................... 1
7. Harness Clamp................................................................... 1
8. Paper Height Sensor........................................................... 1
9. Actuator Arm Bracket.......................................................... 1
10. Sensor Bracket ................................................................. 1
11. Actuator Arm..................................................................... 1
B756I001.WMF
