Installation
1.8 2000/3000 SHEET FINISHERS (B700/B701)
1.8.1 ACCESSORIES
Description Q’ty
1. Cushion (with double-sided tape)........................................... 1
2. Ground (earth) plate............................................................... 1
3. Tapping screws - M4 x14...................................................... 4
4. Tapping screws - M4 x 8....................................................... 2
5. Leveling Shoes ...................................................................... 3
6. Upper output tray................................................................... 1
7. Lower output tray (B700 Only)............................................... 1
8. Front joint bracket .................................................................. 1
9. Rear joint bracket................................................................... 1
10. Gasket Seal ........................................................................... 1
11. Support Tray.......................................................................... 1
12. Support Tray (Not used) ....................................................... 1
13. Accessory Pocket ................................................................. 1
