Toshiba e-STUDIO4500c Service Manual

OUTPUT JOGGER UNIT (B703/B513) August 2006
1-100
1.13 OUTPUT JOGGER UNIT (B703/B513)
The Output Jogger Unit B703 is installed in the 2000/3000 Sheet Finisher
B700/B701.
The Output Jogger Unit B513 is installed in the 3000-Sheet Finisher B706.
1.13.1 ACCESSORIES
Check the accessories and their quantities against this list.
Description
Qty
1. Jogger Unit ................................................................................... 1
2. Tapping Screws - M3 x 6............................................................... 2
WARNING!
Always turn the machine off and disconnect the machine power cord
before you do this procedure.
B703I101.WMF
1
2
