August 2006 PRE-STACK TRAY EXIT SENSOR
B700-11
Peripherals
1.9 PRE-STACK TRAY EXIT SENSOR
• Disconnect the finisher if it is connected to the copier.
[A]: Sensor bracket
[B]: Pre-stack tray exit sensor (S2)
B700R102.WMF
[A]
[B]
