REPLACEMENT AND ADJUSTMENT September 2006
B706-28
3.10 JOGGER UNIT (B513)
3.10.1 JOGGER UNIT
4. Remove the jogger unit cover [A] ( x 2).
5. Remove the jogger unit [B] ( x 2, x 1).
B513I002.WMF
B513R003.WMF
[A]
[B]
06/09
