August 2006 PROOF TRAY FULL SENSOR
B700-9
Peripherals
1.7 PROOF TRAY FULL SENSOR
• Remove the exit guide plate. (1.6)
[A]: Guide plate. Disconnect at ,
[B]: Sensor bracket ( x1)
[C]: Proof tray full sensor (S11) ( x1)
B700R111.WMF
[A]
[B]
[C]
