PAPER FEED August 2006
6-120
Tray Side-to-side Positioning
When the feed tray is set in the feed unit, the side-to-side positioning plate [A]
presses the feed tray against the stopper [B].
By moving the positioning plate, the tray position can be changed to adjust the
side-to-side registration.
B132D951.WMF
B132D952.WMF
[A]
[B]
