ADDITIONAL INFORMATIONS April 2007
4-76
4.4 ADDITIONAL INFORMATIONS
4.4.1 TRAY PAPER SIZE SETTING
SYMPTOM:
The size of the paper in the tray does not match the paper size that is displayed on
the LCD. Sometimes, this causes a jam to occur.
CAUSE:
The operator did not set the side fence or end fence correctly.
Note: This can cause the machine to detect the wrong paper size when “Auto
Paper Size Detection” is ON.
ACTION:
Advise users to:
• Make sure to set the end fence [A] and side fences [B] correctly.
• Make sure to lock the side fence lock [C].
[A]
[B]
[C]
Side fence lock is unlocked.
Side fence lock is locked.
