August, 2006 BOARDS
3-133
3.14 BOARDS
3.14.1 CONTROLLER UNIT
CAUTION
Before you start this procedure, turn off the main power switch and
disconnect the power cord.
Remove
[A]: Disconnect the ARDF
[B]: Controller unit ( x3)
B132R710.WMF
[A]
[B]
