Toshiba e-STUDIO4500c Service Manual

August 2006 PAPER FEED
6-121
Detailed
Descriptions
6.13.9 TRAY POSITIONING MECHANISM – TRAYS 1 TO 3
When the tray is placed in the feed unit, the lock lever [A] drops behind the lock
plate [B] on the support bracket to lock the tray in the proper position.
B132D953.WMF
[A]
[B]
