MFP CONTROLLER OPTIONS August 2006
1-126
USB SP Settings
The following SP commands are available. But, only one setting can be adjusted,
and this must only be done if the customer has USB data transmission errors.
NOTE: Do not change the settings marked “DFU”. These settings are for design
and factory use only.
To go into the SP mode:
1. Press ‘Clear Modes’
2. On the operation panel keypad, input 107.
3. Hold down [Clear/Stop] () for more than 3 seconds.
4. Press “Copy SP” on the touch-panel to open the SP command selection screen.
5. Input 5844.
SP No. Name Function
Adjusts the USB transfer rate. Do not change the setting
unless there is a data transfer error with the USB high
speed mode.
HS/FS:
To Next Page
