Toshiba e-STUDIO4500c Service Manual

3000-SHEET FINISHER (B706), FINISHER ADAPTER (B698) August 2006
1-82
1.11 3000-SHEET FINISHER (B706), FINISHER ADAPTER
(B698)
1.11.1 ACCESSORIES
3000-Sheet Finisher B706 Accessories
Check the accessories and their quantities against this list.
Description Q’ty
1. Table Extension..................................................................... 1
2. Leveling Shoes ...................................................................... 4
3. Rear Joint Bracket ................................................................. 1
4. Front Joint Bracket................................................................. 1
5. Entrance Guide Plate............................................................. 1
6. Ground (Earth) Plate.............................................................. 1
7. Tray Holder (Not used for e-STUDIO4500c/5500c)............... 1
8. Auxiliary Tray (Proof Tray) (Not used) ................................... 1
9. Auxiliary Tray (Shift Tray) (Not used)..................................... 1
10. Phillips Screws w/washer - M4 x 14....................................... 4
11. Tapping Screws - M4 x 8 ....................................................... 2
12. Tapping Screws - M3 x 6 ....................................................... 4
13. Tapping Screws - M3 x 8 ....................................................... 4
14. Shift Tray................................................................................ 1
15. Sponge Cushion .................................................................... 1
B706I201A.WMF
10
11
12
13
1
2
3
4
5
6
7
8
9
14
15
