August, 2006 IMAGE ADJUSTMENTS
3-189
Printer Mode
There are six adjustable modes. Select these modes with in the Printer SP mode
with SP1102 001:
• 1200 x 1200 photo mode
• 600 x 600 text mode
• 1800 x 600 text mode
• 600 x 600 photo mode
• 1800 x 600 photo mode
• 1200 x 1200 text mode
K C M Y
Highlight
Middle
Shadow
ID max
SP1104 001
Adjustment Procedure
1. Do the ACC adjustment for the printer mode.
2. Turn the main power off and on.
3. Enter SP mode.
4. Touch “Printer SP”.
5. Select SP1102 001 and select the print mode that you want to adjust.
6. To review the image quality for these settings, do SP1103 001 to print out a
tone control test sheet.
7. Adjust the color density with SP1104 as shown below while comparing the tone
control test sheet with the C4 test chart.
Important: Always adjust the density in order: ID MaxÆ MiddleÆ ShadowÆ
Highlight
8. Save the adjusted settings with SP1105 001.
To Next Page
