TANDEM TRAY (TRAY 1) August, 2006
3-114
3.11.2 REAR FENCE RETURN SENSOR REPLACEMENT
• Pull out the tandem feed tray.
[A]: Return sensor assembly ( x 1, x1).
B132R623.WMF
[A]
