FUSING UNIT August, 2006
3-90
3.9.5 FUSING CLEANING UNIT
Remove:
• Fusing unit (3.9.2)
[A]: Fusing unit upper cover ( x3)
[B]: Fusing cleaning unit (Spring x1)
B132R408.WMF
[A]
[B]
