Toshiba e-STUDIO4500c Service Manual

August 2006 3000-SHEET FINISHER (B706), FINISHER ADAPTER (B698)
1-83
Installation
Finisher Adapter Kit B698 Accessories
Check the accessories and their quantities against this list.
Description
Qty
1. Upper Transport Motor Bracket.............................................. 1
2. Timing Belt............................................................................. 1
3. Short Connector..................................................................... 1
4. Harness.................................................................................. 1
5. Gasket Seal ........................................................................... 1
6. EPROM.................................................................................. 1
7. Harness Clamps .................................................................... 2
8. Serial Number Decal.............................................................. 1
9. Stopper Bracket ..................................................................... 1
B698I101.WMF
1
2
3
4
5
6
8
7
9
