September 2006 MAIN BOARD
B704-5
Peripherals
1.5 MAIN BOARD
Open the top cover.
Rear cover ( x 1)
[A]: Main board ( x 9,  x 4)
NOTE: All DIP switch settings on the main board of the cover sheet unit should be
set to OFF.
B470R101.WMF
[A]
06/09
