Toshiba e-STUDIO4500c Service Manual

ELECTRICAL COMPONENTS August 2006
B700-28
2.2.3 PUNCH UNIT B702
1. Punch Encoder Sensor (S24)
2. Punch Drive Motor (M24)
3. Punch HP Sensor (S24)
4. Punch Unit Board (PCB3)
5. Paper position sensor slide motor (M7)
6. Paper Position Slide HP Sensor (S22)
7. Paper Position Sensor (S3)
8. Punch Hopper Full Sensor (S4)
9. Punch Movement HP Sensor (S21)
10. Punch Movement Motor (M9)
B700D203A.WMF
1
4
5
6
7
8
9
10
2
3
