4.2 SPECIAL PROCEDURES
4.2.1 SP2181 030 (ALIGNMENT RESULT) ERRORS
After SP2181 030 executes normally, you should see:
1
If you see any number other than a "1", this indicates an error.
Code
Error Problem Recovery
0
None Default display.
1
None No action required.
Large amount of skew.
Large amount of K skew.
Large amount of skew in every color.
Print a trim pattern with SP2109 002 Pattern 10.
Density too light.
Print a coverage pattern with SP2109 002 Pattern 1.
Check the images.
2
Failure
ITB scratched. Replace the ITB.
ITB misaligned. Reinstall ITB.
SP2153 023 set to 1 (OFF). Set SP2153 023 to 0 (ON).
Image density too light.
Output a coverage pattern with SP2109 002 Pattern
1. Check the images.
12
Abnormal detection pattern
Dirty, abnormal images.
Output Pattern 1, 18, or 20 with SP2109 002 and
check the images.
