August 2006 POSITIONING ROLLER
B700-5
Peripherals
1.3 POSITIONING ROLLER
[A]: Open the front door.
[B]: Pull out the stapler unit.
[C]: Positioning roller ( x1, timing belt x1)
B700R103.WMF
[A]
[B]
[C]
