Toshiba e-STUDIO4500c - Ozone Ventilation

August, 2006 PHOTOCONDUCTOR UNITS (PCU)
6-59
Detailed
Descriptions
Ozone Ventilation
The ozone fan [A] pulls air from around the drums through the ozone filter [B] and
then expels the filtered air from the machine.
