August 2006 BASIC PROCEDURES

B700-1

Peripherals

1. REPLACEMENT AND ADJUSTMENT

NOTE: Be careful not to touch the sharp edge on the guide [A] indicated in

the figure.

1.1 BASIC PROCEDURES

1.1.1 COVERS

[A]: Small Upper Cover ( x1). Open the front door, remove the screw, then

remove the cover.

[B]: Upper Cover ( x2)

[C]: Front Door Bracket ( x1)

[D]: Front Door

[E]: Front Left Side Cover ( x2)

[F]: Cover

[G]: Paper Exit Cover ( x2)

[H]: Rear Cover ( x2)

B700R101.WMF
