April, 2007 TEST PATTERN PRINTING
5-9
5.3 TEST PATTERN PRINTING
5.3.1 PRINTING TEST PATTERN: SP2109 002
Some of these test patterns are used for copy image adjustments but most are
used primarily for design testing. These test patterns do not use the IPU.
NOTE: Do not operate the machine until the test pattern is printed out completely.
Otherwise, an SC may occur.
1. Enter the SP mode and select SP2109 002
2. Enter the number for the test pattern that you want to print and press [#].
3. When you are prompted to confirm your selection, press "Yes" to select the test
pattern for printing.
4. Press "Copy Window" to open the copy window, then select the settings for the
test print (paper size, etc.)
5. Press the [Start] () key twice (ignore the “Place Original” messages) to start
the test print.
6. After checking the test pattern, press SP Mode (highlighted) to return to the SP
mode display.
7. Press "Exit" twice to exit the SP mode.
Test Pattern Table
These patterns can be selected with SP2109 002.
0 Off 14 Horizontal Cross-Stitch
1 1-Dot Line 15 Crop Marks
2 1-Dot Slant Cross-Stripe 16 Vertical Belt
3 2-Dot Horizontal Line 17 Checkered Flag
4 2-Dot Vertical Line 18 1-Dot 20 mm Grid
5 1-Dot Horizontal Line 19 1-Dot 20 mm Slant Grid
6 1-Dot Vertical Line 20 Horizontal Grayscale
7 1-Dot Independent 21 Horizontal Grayscale-White Stripes
8 2-Dot Independent
9 4-Dot Independent
10 Trim Area
11 Belt Pattern
12 100% Coverage
13 Vertical Cross-Stitch
