August 2006 IMAGE TRANSFER AND PAPER TRANSFER
6-93
Detailed
Descriptions
6.12.2 ITB DRIVE
[A]: ITB drive motor
[B]: ITB drive roller
[C]: ITB
The ITB drive motor [A] drives the ITB drive roller [B]. All the other rollers inside the
ITB are idle rollers.
B132D307.WMF
[A]
[C]
[B]
