Toshiba e-STUDIO4500c - Cover Interposer Tray B704; Lct B473

PM TABLES August, 2006
2-12
2.3.6 COVER INTERPOSER TRAY B704
60K
120K
180K
EM
Note
The PM interval is for the number of sheets that have been fed.
Feed Belt R R R
Pick-up Roller R R R
Separation Roller
R R R
Replace as a set.
Driver Rollers C C C
Idle Rollers C C C
Discharge Brush C C C
Damp clean cloth.
Sensors C C C Blower brush.
2.3.7 LCT B473
1000K
2000K
3000K Expected
Note
Paper feed roller R R R
Pick-up roller R R R
Separation roller R R R
Transport guide plate
Grip roller
Inspect and clean every 350K.
