FINISHER ENTRANCE SENSOR August 2006
B700-10
1.8 FINISHER ENTRANCE SENSOR
• Disconnect the finisher if it is connected to the copier.
• Disconnect the cover interposer if it is installed.
[A]: Sensor bracket ( x1)
[B]: Finisher entrance sensor (S1) ( x1)
B700R133.WMF
[A]
[B]
