TONER SUPPLY UNIT
August, 2006
3-60
3.6.2
CONNECTOR BOA
RD (CNB)
Remove:
•
Open the
front door
.
•
Remove th
e toner
hop
per (
3.2.
7)
[A]:
Support bracket (
x2)
[B]: CNB
(
x8,
x1)
. Slide the PC
B ass
embly to th
e rig
ht and re
move it.
B132R216.
WMF
[A]
[B]
