Toshiba e-STUDIO4500c Service Manual

August, 2006 PM TABLES
2-11
2.3.2 2000/3000-SHEET BOOKLET FINISHER B700/B701
300K
2400K
3000K
4000K
EM Note
FINISHER
Covers I,C Alcohol or water, dry cloth
Drive Rollers C Damp cloth, dry cloth
Idle Rollers C Damp cloth, dry cloth
Anti-Static Brush C Dry cloth
Sensors C Blower brush
Corner Stapler R
Print an SMC report with
SP5990. Replace the unit if
the staple count is 500K.
Booklet Stapler R
Print an SMC report with
SP5990. Replace the unit if
the staple count is 200K.
2.3.3 PUNCH B702
PUNCH
300K
2400K
3000K
4000K
EM
Punch Waste Hopper I I I I I Remove and empty
Punch Unit
Replace after 1000k
punches.
2.3.4 3000-SHEET FINISHER B706
350K
700K
1050K
Note
FINISHER
Driver rollers I I I
Idle rollers I I I
Discharge brush I I I
Alcohol
Shaft Bearings I I I Lubricate with silicone oil if noisy.
Sensors I I I Blower brush.
Jogger fences I I I Make sure that the screws are tight.
Staple waste hopper C C C Empty staple waste.
2.3.5 PUNCH B531
PUNCH
300K
450K
600K
EM Note
Punch Waste Hopper I I I Remove and empty
