Toshiba e-STUDIO4500c - Page 182

August, 2006 PM TABLES
2-9
150K
300K
600K
EM Note
PAPER FEED (Trays)
Feed Guide Plate C Dry cloth
Grip Rollers (Drive & Idle) C Alcohol, dry cloth
Pick-up Rollers (Tray 1 to Tray 3)
Paper Feed Rollers (Tray 1 to Tray
3)
Separation Rollers (Tray 1 to Tray 3)
Service Life: 1000K
Replace if jams,
double-feeds occur
with increasing
frequency.
Grip Roller (Drive Roller) C Dry cloth
Paper Feed Sensor C Blower brush
Vertical Feed Sensors C Blower brush
Paper-End Sensor C Blower brush
150K 300K 600K
EM
Note
DUPLEX UNIT
Inverter Roller C Blower brush
Reverse Rollers (Drive & Idle) C Alcohol, dry cloth
Duplex Rollers C Dry cloth
Transport Rollers (x4) C Dry cloth
Duplex Entrance Anti-Static Brush C Dry cloth
Inverter Junction Gate C Dry cloth
Inverter Roller C Dry cloth
150K
300K
600K EM Note
PAPER EXIT
Heat Dissipation Roller C Alcohol, dry cloth
Exit Anti-Static Brush C
Inspect, replace if
deformed.
Paper Exit Rollers (Upper, Lower) C Alcohol, dry cloth
Paper Exit Sensor C Blower brush
Transport Rollers C Blower brush
