Toshiba e-STUDIO4500c Service Manual

PM TABLES August, 2006
2-8
150K
300K
600K
EM
Note
FUSING UNIT
Fusing Belt R
Hot Roller R
Pressure Roller R
Hot Roller Cleaning Roller R
Pressure Roller Cleaning Felt Roller R (3.9.9)
Fusing Belt Lubrication Roller R
Heating Roller C, L
Heating Roller Shaft Bearings Service Life: 1200K
Hot Roller Shaft Bearings C, L Service Life: 1200K
Pressure Roller Shaft Bearings R
Hot Roller Cleaning Roller Shaft
Bearings
C, L Service Life: 1200K
Fusing Belt Strippers / Pressure Roller
Strippers
C, L
Dry Cloth
Thermistors C
150K
300K
600K EM
Note
OTHER
Circuit Breaker
Check the operation
one a year.
Dust Filters R
Ozone Filters Service Life: 1200K
Waste toner bottle IR IR IR
Empty and clean
every inspection.
150K 300K 600K
EM Note
PAPER FEED (Copier)
Registration Rollers C Alcohol, dry cloth
Paper Dust Removal Unit C Dry cloth
Registration Sensor C Blower brush
Vertical Transport Roller
Sensors
C Blower brush
LCT Relay Sensor C Blower brush
Bypass Feed Sensor C Blower brush
Bypass Paper End Sensor C Blower brush
Double-Feed detection
Sensor
C Blower brush
Double Feed Detection LED C Blower brush
