Symbol Name Function
S34 Bottom Fence HP
Detects the bottom fence home position for Z-fold
paper staple mode.
Symbol Name Function
SOLENOIDS
SOL1
(Upper) Tray Junction
Gate
Drives the tray junction gate.
SOL2 Stapler Junction Gate
Drives the stapler junction gate.
SOL3 Pre-Stack Junction Gate
Drives the stopper pawl of the pre-stacking tray.
SOL5 Stapler Return
Positions the stapler correctly on its return from the
staple supply point.
SWITCHES
SW1 Shift Tray Upper Limit
Cuts the power to the shift tray lift motor when the
shift tray position is at its upper limit.
SW2 Front Door Safety
Cuts the dc power when the front door is opened.
SW3 Emergency Stop
Switches the current job off and on to allow time for
the operator to remove paper from the shift tray.
06/09
