Toshiba e-STUDIO4500c Service Manual

MAILBOX (B762) August 2006
1-80
2. If the Cover Interposer Tray B704 is installed on the B700/B701, remove it.
NOTE: The cover interposer tray and mail box cannot be installed on the
finisher at the same time.
3. Remove the top cover [A] of the finisher ( x1).
4. Remove the bracket [B] ( x1).
B762I102.WMF
[A]
[B]
